Leica Magnus 1-6.3×24 i L-4a Reticle

R52,200.00 Inc VAT

Available on backorder

Notify me when stock is available again

SKU: 52120

Description

The Leica Magnus 1-6.3×24 i L-4a is an extremely versatile riflescope for hunting from blinds and when stalking. Due to its combination of maximum resolving power, an extremely broad overview and an astoundingly wide field of view of 44 metres at 100 metres, the Magnus 1-6.3×24 i ensures significantly greater safety and hunting success. Thanks to a large exit pupil and a crisply defined, extremely bright red dot, it guarantees extremely fast and accurate target location, especially with running game. The riflescope features a generously wide 1 to 6.3-fold zoom range, and a smart, automatic power-off function. In combination with its extremely compact construction, these features make the Magnus 1–6.3×24 i an extraordinarily reliable and versatile companion on any hunt.

Leica-Magnus-1.8-12x50-i-L-4a-Habitat-AfricaLeica Magnus 1-6.3×24 i L-4a Reticle Features

  • Crosshair thickness: 0.5 cm
  • Distance between horizontal posts: 140 cm
  • Use: universal hunting reticle for a precise shot
  • Astoundingly wide field of view of 44 m/144 ft. at 100 m/328 ft. for a better overview
  • Thanks to a large exit pupil it guarantees extremely fast and accurate target location.
  • Up to 6.3-fold zoom for maximum safety and flexibility during driven hunt
  • Excellent transmission and extraordinary contrast to ensure optimum identification of game
  • Extremely bright red dot.
  • Outstanding ergonomics and easy handling – even when wearing gloves.
  • Smart, automatic power-off function for maximum battery-life

Leica Magnus i

Unbeatable by day, by dusk and at long distances. Leica Sport Optics has now taken the successful Magnus riflescope series to the next level. The Magnus models of the second generation are very reliable, flexible companions for every demanding hunter and deliver razor-sharp, crystal-clear images. The Magnus i riflescope line offers the right solution for all hunt types – from driven hunts to long-range hunting.

Leica-Magnus-i-Habitat-Africa-2

The world through Leica eyes

What makes Leica riflescopes so special is their superior field of view. When combined with effective stray-light suppression, excellent transmission and maximum contrast for bright images. This guarantees safe target identification in every situation, even when conditions are difficult.
Enjoy freedom from distracting keyhole effects when it really counts. The extremely wide field of view provides a subjectively higher image brightness than smaller fields of view, and the Magnus i’s greater gives you a safer hunting experience. The greater magnification range ensures an enormous application spectrum and makes the Magnus i the best riflescope for every kind of hunting. The Magnus 1.5 – 10×42 i, for example, is the perfect companion for driven hunts, stalking, and hunting from a high seat, as well for mountain hunts.
At the same time, high technical demands had to be satisfied to produce the Magnus i series, so that uncompromising quality and 100% reliability are guaranteed – giving you both maximum flexibility and precision for close as well as long-range shots.

Leica-Magnus-i-Habitat-Africa-1

Convincing in all light conditions

Functionality and ease of handling are among the most important aspects of product development. This is where Leica combines years of experience with technological innovation. With the result that the Leica Magnus i riflescope series allows safe hunting even in unfavorable light conditions.
This is ensured by the exceptionally precise adjustment mechanism that regulates the illuminated dot. The sensitive brightness control features a day/night setting and is adjustable in 60 micro steps. With the press and hold function, you can run through the whole range and store your last brightness setting. On top of that, the reticle’s intelligent auto on/off function prolongs battery life considerably, by switching off the illumination when not required, for instance when in an unsuitable shooting position.
The challenge of developing the perfect illuminated dot lies in finding the balance between “as small as possible” and “sensibly large”. Leica has found the solution with a very small illuminated dot that is so fine that it covers the target only minimally, but is at the same clearly visible because of its crispness. For the reticles, Leica relies on a technology known as “phase gratings”, where nano structures are etched into the glass, shaping the light with high efficiency. That’s how you keep the critical overview and always identify every important detail – for a successful hunt.

Leica-Magnus-i-Habitat-Africa

Better vision means safer targeting

Thanks to multilayer plasma lens coatings, Leica achieves natural color fidelity and outstanding light transmission. During construction, the lenses are covered with plasma layers that are only a few nanometers thick and are evaporated in a vacuum using a high-temperature plasma process. All lenses are made exclusively of glass produced by highly respected manufacturers – for minimal absorption.
Every riflescope offers particularly low vignetting – for maximum light-gathering power, especially at low magnification.
Leica possesses extraordinary expertise when it comes to stray-light suppression. For the simulation of stray-light and reflection, Leica uses its own software. The optimization of lens distances, diameters and radii, along with the precise placing of light traps and baffles, have always been important elements in the development and manufacturing of Leica riflescopes and binoculars – for crisp and clear images.
Maximum contrast means: black is black and not dark grey; white is white and not light grey. High-resolution optics can only realize their true potential with maximum contrast. Using a combination of stray-light suppression, a choice of superior glass types and bold and extreme lens shapes, Leica creates fantastic contrast, giving you precise and detailed images, even in poor light.

Package includes:

  • Riflescope
  • ZF caps for eyepiece/lens
  • Battery (CR 2032)
  • Cleaning tissue

Magnus i Reticles and subtensions
Magnus i Technical Data

Leica-Magnus-i-Habitat-Africa-3



Leica Magnus 1-6.3×24 i L-4a Reticle

Device type: Riflescope
Scope of delivery: Riflescope caps for front lens / eyepiece, cleaning tissue, battery, instruction manual
Front lens diameter: 24 mm
Magnification: 1–6.3x
Zoom: 6,3 x
Field of view at 100 m (min. up to max. magnification): 44 m to 6.5 m
Eye relief: > 3.5 in / 90 mm
Exit pupil: 12,4 – 3,8 mm
Parallax-free: 100 m
Diopter compensation: –4/+3 dpt
Coating: AquaDura® lens coating
Transmission: approx. 92%
Focal plane reticle: 2nd focal plane
Available reticles: L-4a, L-3D
Reticle adjustment (100 m): 400×400 cm
Impact point correction (100 m): 1 click = 1 cm / 100 m (~1⁄3 MOA)
Reticle illumination: dot
Size illuminated dot (10 x magnification): 2.4 cm/100 m
Light levels: 120
Central tube diameter: 30 mm
Mounting option: 1.18 in / 30 mm rings / Zeiss internal rail
Front lens filter thread: M28x0.75
Length: 10.7 in/272 mm
Weight: 19.2 oz/544 g (with rail: 22.2 oz/570 g)
Waterproof: waterproof to 13.1 ft / 4 m; nitrogen-filled
Automatic switch-of: 3 min, ± 75°
Automatic switch-on: yes, activated by position and/or movement
Battery: 1 x CR2032
Order No. (Reticle): L-4a / with rail 52120/52121
Order No. (Reticle): L-4a with BDC / with rail
Order No. (Reticle): L-3D/with rail 52110/52111
